2-těsnící
Kód produktu:
XYZ_123_00073
tělesa ventilu z jedné části bez mrtvých prostorů, bezpečnost CIP / SIP-čištění, standard-O-kroužky několik těsnění nízké náklady na náhradní díly
Popis
|
Technical Data |
||
|
Material |
in product contact optional non product contact |
1.4404/AISI316L 1.4435/AISI316L 1.4301/AISI304 |
|
Seals |
O-rings |
EPDM (FDA) |
|
Temperatures maximum |
operating temperature sterilisation temperature |
130 °C 150 °C* short-time (ca. 20 min) |
|
Operating pressure |
closing pressure actuator air pressure |
max. 6 bar min 6 bar - max. 10 bar |
|
Surfaces |
in product contact optional non product contact |
Ra <= 0,8 μm e-polished, other surfaces on request Ra <=1,6 μm |
|
Connections Standard- pipes |
DIN 11850-R2 (DIN 11866 A) O.D.-Tube (DIN 11866 C) DIN EN ISO 1127 (DIN 11866-B) |
|
Your advantages |
|
|
Design |
one-part solid valve body no dead space safe CIP/SIP-cleaning |
|
Absolute product safety |
radial sealing of valve disk safe separation of products leakage is safely drained-off |
|
Serviceable maintenance |
change of seals without special tools service without danger as spring is in a cage service possible without compressed air valve insert completely removable upwards |
|
Efficiency |
standard-O-rings few seals low spare part costs |
